ABB TA0107L - Page 14

14
Table 9 - V-Drive Center Distances
TA8407H
Reducer
Position Mounting.
Motor Frame / Motor Shaft Offset Dimension “A”
210T / A=1.55 250T / A=1.56 280T / A=1.16 320T / A=.38 360T / A=1.01 400T / A=.75 440T
A
M1 27.4 – 31.3 28.3 – 32.3 29.1 – 33.0 30.1 – 34.0 31.0 – 35.0 32.0 – 36.0 ----
M2 33.2 – 37.2 34.2 – 38.2 35.0 – 39.0 36.0 – 39.9 37.0 – 40.9 37.9 – 41.9 ----
M3 39.2 – 43.2 40.2 – 44.2 40.9 – 44.9 41.9 – 45.9 42.9 – 46.9 43.9 – 47.9 ----
M4 45.1 – 49.1 46.1 – 50.1 46.9 – 50.9 47.9 – 51.9 48.8 – 52.8 49.8 – 53.8 ----
B
M1 30.2 – 34.2 31.2 – 35.2 32.0 – 35.9 32.9 – 36.9 33.9 – 37.9 34.9 – 38.9
M2 36.2 – 40.1 37.1 – 41.1 37.9 – 41.9 38.9 – 42.9 39.9 – 43.9 40.9 – 44.9 ----
M3 42.1 – 46.1 43.1 – 47.1 43.8 – 47.8 44.8 – 48.8 45.8 – 49.8 46.8 – 50.8 ----
C
M1 17.6 – 21.4 18.5 – 22.4 19.2 – 23.1 20.2 – 24.1 21.2 – 25.1 22.1 – 26.0 ----
M2 23.3 – 27.3 24.3 – 28.2 25.0 – 29.0 26.0 – 30.0 27.0 – 30.9 28.0 – 31.9 ----
M3 29.2 – 33.2 30.2 – 34.1 30.9 – 34.9 31.9 – 35.9 32.9 – 36.9 33.9 – 37.8 ----
M4 35.1 – 39.1 36.1 – 40.1 36.8 – 40.8 37.8 – 41.8 38.8 – 42.8 39.8 – 43.8 ----
D
M1 20.3 – 24.2 21.3 – 25.2 22.0 – 25.9 23.0 – 26.9 23.9 – 27.9 24.9 – 28.9 ----
M2 26.1 – 30.1 27.1 – 31.1 27.9 – 31.8 28.8 – 32.8 29.8 – 33.8 30.8 – 34.8 ----
M3 32.1 – 36.0 33.0 – 37.0 33.8 – 37.8 34.8 – 38.8 35.8 – 39.7 36.7 – 40.7 ----
TA9415H
Reducer
Position Mounting.
Motor Frame / Motor Shaft Offset Dimension “A”
250T / A=1.56 280T / A=1.16 320T / A=.38 360T / A=1.01 400T / A=.75 440T / A=1.62 440T
A
M1 N/A N/A N/A N/A N/A N/A ----
M2 N/A N/A N/A N/A N/A N/A ----
M3 N/A N/A N/A N/A N/A N/A ----
M4 N/A N/A N/A N/A N/A N/A ----
B
M1 35.5 – 39.2 36.2 – 40.0 37.2 – 41.0 38.2 – 42.0 39.2 – 43.0 40.2 – 44.0 ----
M2 40.5 – 44.2 41.2 – 45.0 42.2 – 46.0 43.2 – 47.0 44.2 – 47.9 45.2 – 48.9 ----
M3 N/A N/A N/A N/A N/A N/A ----
C
M1 N/A N/A N/A N/A N/A N/A ----
M2 N/A N/A N/A N/A N/A N/A ----
M3 N/A N/A N/A N/A N/A N/A ----
M4 N/A N/A N/A N/A N/A N/A ----
D
M1 21.3 – 25.0 22.0 – 25.7 23.0 – 26.7 24.0 – 27.7 25.0 – 28.7 25.9 – 29.7 ----
M2 26.2 – 29.9 26.9 – 30.6 27.9 – 31.6 28.9 – 32.6 29.9 – 33.6 30.9 – 34.6 ----
M3 N/A N/A N/A N/A N/A N/A ----
TA10507H
Reducer
Position Mounting.
Motor Frame / Motor Shaft Offset Dimension “A”
250T / A=1.56 280T / A=1.16 320T / A=.38 360T / A=1.01 400T / A=.75 440T / A=1.62
A
M1 N/A N/A N/A N/A N/A N/A
M2 N/A N/A N/A N/A N/A N/A
M3 N/A N/A N/A N/A N/A N/A
M4 N/A N/A N/A N/A N/A N/A
B
M1 46.7 – 50.5 47.5 – 51.2 48.5 – 52.2 49.5 – 53.2 50.5 – 54.2 51.5 – 55.2
M2 52.1 – 55.9 52.8 – 56.6 53.8 – 57.6 54.8 – 58.6 55.8 – 59.6 56.8 – 60.6
M3 N/A N/A N/A N/A N/A N/A
C
M1 N/A N/A N/A N/A N/A N/A
M2 N/A N/A N/A N/A N/A N/A
M3 N/A N/A N/A N/A N/A N/A
M4 N/A N/A N/A N/A N/A N/A
D
M1 17.7 – 21.4 18.4 – 22.2 19.4 – 23.2 20.4 – 24.2 21.4 – 25.2 22.4 – 26.2
M2 23.0 – 26.8 23.8 – 27.5 24.8 – 28.5 25.8 –29.5 26.8 – 30.5 27.8 – 31.5
M3 N/A N/A N/A N/A N/A N/A
