Table 16 - Parts for TA6307H through TA12608H Taper Bushed and Single Reduction Reducers
Ref. Description Quantity TA6307H TA7315H TA8407H TA9415H TA10507 TA12608
38 First Stage Gear
9:1 Ratio ⑥
15:1 Ratio ⑥
25:1 Ratio ⑥
40:1 Ratio ⑥
1
1
1
1
906217
906215
906213
906211
907217
907215
907213
907211
N/A
908215
908213
908211
N/A
909215
909213
909211
N/A
910215
910213
910211
N/A
912215
912213
912211
39 Counter-Shaft Pinion 1 906209 907209 908209 909209 910209 912209
40 First Stage Gear Key 1 906276 907276 908276 909276 910276 912276
41
Countershaft Bearing Shim-As
Required
.015” Shim
.007” Shim
.005” Shim
906271
906273
906272
906271
906273
906272
908267
908269
908268
909267
909269
909268
904263
909265
904264
912267
912269
912268
44 Auxiliary Output Seal 2 906236 907236 907236 909236 910236 912236
45 Auxiliary Input Seal
5:1, 9:1 Ratio ⑥
15:1, 25:1 Ratio ⑥
40:1 Ratio ⑥
1
1
1
901236
901236
901236
907238
907238
907238
N/A
907238
907238
N/A
907238
907238
N/A
902236
902236
N/A
902236
902236
100 Torque-Arm Adapter Bracket 2 906500P 907500P 907500P 909500P 910500P 912500P
Torque-Arm Rod Kit ⑦ 1 964269 964275 964275 965682 965682 965683
101 ⑧ Torque-Arm Rod End ⑩ 1 A73269 A73101 A73101 964278 964278 964284
102 ⑧ Torque-Arm Extension ⑩ 1 A73265 963479 963479 964280 964280 964286
103 ⑧ Torque-Arm Turnbuckle ⑩ 1 A73267 A73102 A73102 964279 964279 964285
104 ⑧ RH Nut ⑩ 1 A73268 407103 407103 407107 407107 964290
105 ⑧ LH Nut ⑩ 1 A73266 A73270 A73270 965051 965051 964289
106 Torque-Arm Bushing 1 247244 271046 271046 272046 272046 272187
107 Torque-Arm Fulcrum 1 247248 271054 271054 272054 272054 272154
108 Torque-Arm Bolt 1 411489 411510 411510 411520 411520 411527
109 Torque-Arm Lockwasher 1 034017018AB 419020 419020 419024 419024 419025
110 Torque-Arm Nut 1 407093 407099 407099 407104 407104 407108
111 Torque-Arm Bolt 1 411489 411516 411516 419524 411524 411528
112 Torque-Arm Nut 1 407093 407099 407099 407104 407104 407108
113 Lockwasher 1 034017018AB 419020 419020 419024 419024 419025
200 Bushing Back-Up Plate 2 906301 272037 908301 909301 910301 912301
203 Retaining Ring 2 906304 421098 908304 909304 910304 912304
204 Bushing Cap Screw 6 ⑨ 411456 411457 411457 032018016EJ 032018016EJ 032018016EJ
205 Bushing Lockwasher 6 ⑨ 419013 419013 419013 032018016EJ 032018016EJ 032018016EJ
400 Screw Conveyor Adapter 1 906401 907401 N/A N/A N/A N/A
401 Screw Conveyor Keeper Plate 1 906402 907402 N/A N/A N/A N/A
402 Screw Conveyor Wedge 1 906403 907403 N/A N/A N/A N/A
403 Screw Conveyor Drive Shaft
2-7/16” Shaft
2-7/16” Shaft,
Stainless Steel
3” Shaft
3” Shaft, Stainless
Steel
3-7/16” Shaft
3-7/16” Shaft,
Stainless Steel
1
1
1
1
1
1
906074
906082
906075
906083
906076
906084
907074
907082
907075
907083
907076
907084
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
404 Retaining Bolt 1 966138 966138 N/A N/A N/A N/A
405 Lockwasher 1 419020 419020 N/A N/A N/A N/A
406 Drive Shaft Key 1 906405 907405 N/A N/A N/A N/A
407 Drive Shaft Washer 1 906404 907404 N/A N/A N/A N/A
408 Seal 2 906411 907411 N/A N/A N/A N/A
409 Bolt 4 411983 411493 N/A N/A N/A N/A
410 Lockwasher 4 034017020AB 034017020AB N/A N/A N/A N/A
411 Retaining Ring 1 906446 907446 N/A N/A N/A N/A
412 Adjustable Packing Retainer 1 906413 907413 N/A N/A N/A N/A
413 Adjustable Packing Gland Stud 2 400404 400404 N/A N/A N/A N/A
414 Adjustable Packing Gland Nut 2 407202 407202 N/A N/A N/A N/A
415 Sealing Rings 3 906416 907416 N/A N/A N/A N/A
600 Backstop Assembly
5:1, 9:1 ⑥
15:1 Ratio ⑥
25:1 Ratio ⑥
40:1 Ratio ⑥
1 906102 907102 N/A N/A N/A N/A
1 906102 907102 908102 909102 910102 912102
1 906103 907102 908102 909102 910102 912102
1 906103 907103 908103 907103 910103 912103
NOTES:
① Not shown on drawing.
② 8 required on TA6307H, TA7315H, TA8407H and TA9415H; 12 required on TA10507H and TA12608H.
③ 18 required on TA9415H; 20 required on T10507H; 22 required on TA12608H
④ 36 required on TA9415H; 40 required on TA10507H; 44 required on TA12608H
⑤ 2 required on TA7315H, TA8407H, TA9415H, and TA10507H
⑥ See Table 14 for actual ratio.
⑦ Includes parts listed immediately below marked ⑧.
⑧ Makes up assembly under which it is listed marked ⑦
⑨ 8 required on TA12608H
⑩ Zinc plated as of 2016
