Table 17 - Actual Ratios
Reducer Size
Nominal Ratios
5:1 9:1 15:1 25:1 40:1
TA0107L 5.200 9.000 14.928 25.091 30.942
TA1107H 5.000 8.990 14.912 25.064 30.909
TA2115H 5.200 9.103 15.619 25.067 33.333
TA3203H 4.913 9.234 15.067 24.954 32.451
TA4207H 5.000 9.231 15.000 25.125 39.107
TA5215H 5.105 9.183 14.923 24.996 38.907
TA6307H 4.944 9.215 15.451 24.868 38.319
TA7315H 5.188 9.716 14.914 24.837 39.656
TA8407H N/A N/A 15.120 24.965 39.667
TA9415H N/A N/A 15.103 25.435 39.406
TA10507H N/A N/A 15.092 25.184 39.676
TA12608H N/A N/A 14.788 25.025 38.188
