Table 3–Oil Volumes
Approximate
Reducer Size
Volume of Oil to Fill Reducer to Oil Level Plug ① ④
② Position A ② Position B ② Position C ② Position D ② Position E ② Position F
③ Quart Liter ③ Quart Liter ③ Quart Liter ③ Quart Liter ③ Quart Liter ③ Quart Liter
TA0107L
Single 0.7 0.6 0.5 0.5 0.7 0.6 1.4 1.3 1.3 1.2 1.5 1.4
Double 0.7 0.6 0.5 0.5 0.6 0.6 1.3 1.3 1.2 1.2 1.4 1.3
TA1107H
Single 1.3 1.3 0.7 0.7 0.7 0.6 1.7 1.6 1.5 1.4 1.9 1.8
Double 1.3 1.3 0.7 0.7 0.6 0.6 1.7 1.6 1.5 1.4 1.9 1.8
TA 2115H
Single 2.1 2.0 1.2 1.2 1.1 1.0 2.7 2.5 2.3 2.2 3.1 2.8
Double 2.1 2.0 1.1 1.1 1.0 1.0 2.6 2.5 2.4 2.3 3.0 2.9
TA3203H
Single 2.8 2.7 1.6 1.6 1.8 1.7 4.1 3.9 3.3 3.1 4.4 4.2
Double 2.8 2.7 1.5 1.4 1.7 1.6 4.0 3.8 3.4 3.3 4.2 4.0
TA4207H
Single 4.4 4.2 2.6 2.5 2.9 2.8 7.4 7.0 6.3 6.0 7.8 7.3
Double 4.4 4.2 2.5 2.4 2.8 2.6 7.3 6.9 6.4 6.0 7.5 7.1
TA5215H
Single 7.4 7.0 4.9 4.7 5.8 5.5 13.2 12.5 11.6 11.0 13.1 12.4
Double 7.4 7.0 4.7 4.4 5.5 5.2 12.9 12.2 11.4 10.8 12.6 11.9
TA6307H
Single 8.8 8.4 5.8 5.5 6.6 6.2 16.1 15.3 13.2 12.5 16.1 15.3
Double 8.8 8.4 5.5 5.2 6.2 5.9 15.8 15.0 13.9 13.1 15.3 14.5
TA7315H
Single 8.4 8.0 11.8 11.1 13.9 13.2 22.5 21.3 22.1 20.9 25.1 23.7
Double 8.4 8.0 10.8 10.3 13.2 12.5 22.0 20.9 22.4 21.2 23.1 21.8
TA8407H
Single N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
Double 7.7 7. 3 11.7 11.1 13.7 12.9 25.1 23.8 24.0 22.7 25.8 24.4
TA9415H
Single N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
Double 17.0 16.1 16.8 15.9 18.1 17.1 33.2 31.4 33.2 31.4 38.6 36.5
TA10507H
Single N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
Double 38.0 36.0 27.6 26.1 25.8 24.4 53.5 50.6 53.8 50.9 5 6.1 53.0
TA12608H
Single N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
Double 53.0 50.2 41.5 39.3 37.1 35.1 70.7 66.9 72.2 68.3 80.4 76.1
① Oil quantity is approximate. Service with lubricant until oil runs out of oil level hole.
② Refer to Figure 1 for mounting positions.
③ US measure: 1 quart = 32 fluid ounces = .94646 liters.
④ Below 15 RPM output speed, oil level must be adjusted to reach the highest oil level plug. If reducer position is to vary from those shown in Figure 1, either more or less oil may
be required. Consult Mechanical Power Transmission Support, Greenville, SC
⑤ Reducers with a 5:1 ratio are single-reduction. All other ratios are double-reduction
