Table 4 – Oil Recommendations
Output
RPM
ISO Grades For Ambient Temperatures of 50˚ F to 125˚ F * (10˚ C to 51˚ C)
Torque-Arm II Reducer Size
TA0107L TA1107H TA2115H TA3203H TA4207H TA5215H TA6307H TA7315H TA8407H TA9415H TA10507H TA12608H
301 – 400 320 320 320 220 220 220 220 220 220 220 220 220
201 – 300 320 320 320 220 220 220 220 220 220 220 220 220
151 – 200 320 320 320 220 220 220 220 220 220 220 220 220
126 – 150 320 320 320 220 220 220 220 220 220 220 220 220
101 – 125 320 320 320 320 220 220 220 220 220 220 220 220
81 – 100 320 320 320 320 320 220 220 220 220 220 220 220
41 – 80 320 320 320 320 320 220 220 220 220 220 220 220
11 – 40 320 320 320 320 320 320 320 320 320 320 220 220
1 – 10 320 320 320 320 320 320 320 320 320 320 320 320
Output
RPM
ISO Grades For Ambient Temperatures of 15˚ F to 60˚ F * (-9.4˚ C to 15˚ C)
Torque-Arm II Reducer Size
TA0107L TA1107H TA2115H TA3203H TA4207H TA5215H TA6307H TA7315H TA8407H TA9415H TA10507H TA12608H
301 – 400 220 220 220 150 150 150 150 150 150 150 150 150
201 – 300 220 220 220 150 150 150 150 150 150 150 150 150
151 – 200 220 220 220 150 150 150 150 150 150 150 150 150
126 – 150 220 220 220 150 150 150 150 150 150 150 150 150
101 – 125 220 220 220 220 150 150 150 150 150 150 150 150
81 – 100 220 220 220 220 220 150 150 150 150 150 150 150
41 – 80 220 220 220 220 220 150 150 150 150 150 150 150
11 – 40 220 220 220 220 220 220 220 220 220 220 150 150
1 – 10 220 220 220 220 220 220 220 220 220 220 220 220
NOTES:
1. Assumes auxiliary cooling where recommended in the catalog.
2. Pour point of lubricant selected should be at least 10°F lower than expected minimum ambient starting temperature.
3. Extreme pressure (EP) lubricants are not necessary for average operating conditions. When properly selected for specific applications, TORQUE-ARM II backstops are suitable
for use with EP lubricants.
4. Special lubricants may be required for food and drug industry applications where contact with the product being manufactured may occur. Consult a lubrication manufacturer’s
representative for his recommendations.
5. For reducers operating in ambient temperatures between -22°F (-30°C) and 20°F (–6.6°C) use a synthetic hydrocarbon lubricant, 100 ISO grade or AGMA 3 grade (for example,
Mobil SHC627). Above 125°F (51°C), consult Mechanical Power Transmission Support, Greenville, SC for lubrication recommendation.
6. Mobil SHC630 Series oil is recommended for high ambient temperatures.
GUIDELINES FOR TORQUE-ARM II
REDUCER LONG-TERM STORAGE
During periods of long storage, or when waiting for delivery or
installation of other equipment, special care should be taken to
protect a gear reducer to have it ready to be in the best condition
when placed into service.
By taking special precautions, problems such as seal leakage
and reducer failure due to lack of lubrication, improper
lubrication quantity, or contamination can be avoided. The
following precautions will protect gear reducers during periods
of extended storage:
Preparation:
1. Drain oil from the unit. Add a vapor phase corrosion inhibiting
oil (VCI-105 oil by Daubert Chemical Co.) in accordance with
Table 5.
2. Seal the unit airtight. Replace the vent plug with a standard
pipe plug and wire the vent to the unit.
3. Cover all unpainted exterior parts with a waxy rust
preventative compound that will keep oxygen away from
the bare metal. (Non-Rust X-110 by Daubert Chemical Co.
or equivalent).
4. The instruction manuals and lubrication tags are paper and
must be kept dry. Either remove these documents and store
them inside, or cover the unit with a durable waterproof
cover which can keep moisture away.
5. Protect reducer from dust, moisture, and other contaminants
by storing the unit in a dry area.
6. In damp environments, the reducer should be packed inside
a moisture-proof container or an envelope of polyethylene
containing a desiccant material. If the reducer is to be stored
outdoors, cover the entire exterior with a rust preventative.
When placing the reducer into service:
1. Fill the unit to the proper oil level using a recommended
lubricant. The VCI oil will not affect the new lubricant.
2. Clean the shaft extensions with petroleum solvents.
3. Assemble the vent plug into the proper hole.
4.
Follow the installation instructions provided in this manual.
Table 5 – Quantities of VCI #105 Oil
Reducer Size Quantity (Ounces / Milliliter)
TA0107L 1 / 30
TA1107H 1 / 30
TA 2115H 1 / 30
TA3203H 1 / 30
TA4207H 1 / 30
TA5215H 2 / 59
TA6307H 2 / 59
TA7315H 3 / 89
TA8407H 3 / 89
TA9415H 4 / 118
TA10507H 6 / 177
TA12608H 8 / 237
VCI #105 and #10 are interchangeable.
VCI #105 is more readily available.
