List of components supplied
All the components required to correctly install and connect the inverter
are supplied together with the inverter.
Available components Quantity
Bracket for wall mounting 1
M5x10 screw for the external ground connection 1
M5 contact washer for the external ground connection 2
(Spare part) T20 screw for front cover 1
T20 screws for wall bracket locking 1
Watertight connector for AC cable connection 1
Cable with faston isolated for the conguration of the input
channels in parallel
1+1
Wireless Antenna 1
In addition to what is explained in this guide, the safety and installation information provided in the installation manual must be read and followed.
The technical documentation and the interface and management software for the product are available at the website.
XXXXXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXXXXX
ABB solar inverters
Technical documentation 1
