CONTROL DEVICE ADJUSTMENT
FIGURE A11
1. ROLLER, CLOSE LATCH
2. CHARGING CAM
3. ACTUATOR, LIMIT SWITCH
4. CONTROL DEVICE
5. CLOSE LATCH RELEASE ROD
6. SPRING, CLOSE LATCH RELEASE ROD
7. SECONDARY CLOSE LATCH
8. PRIMARY CLOSE LATCH
1
2
3
4
5
6
8
7
