Programming 5 – 4 Advant Controller AC 31 / Issued: 01.99
3
Type Variables Description
from to
Digital inputs
E 00,00 E 61,15 CS31 system bus digital inputs
E 62,00 E 62,07 Digital inputs on the basic unit
E 63,00 E 68,15 Digital inputs on the basic unit extensions
Analog inputs
EW 00,00 EW 61,15 CS31 system bus analog inputs
EW 62,00 1
st
potentiometer of the basic units
EW 62,01 2
nd
potentiometer of the basic units
EW 62,02 EW 62,07 Reserved variables
EW 62,08 Seconds (0...59)
EW 62,09 Minutes (0...59)
EW 62,10 Hours (0...23)
EW 62,11 Days of the week (1...7)
EW 62,12 Days of the month
EW 62,13 Months
EW 62,14 Years
EW 62,15
Word status:
bit 0: display of class 2 errors
bit 1: used in the in slave basic units for CS31 system bus
recognition
bits 8 to 15: used on the master basic units: they indicate the
number of remote units recognized on the CS 31 system bus.
EW 63,00 EW 68,15 Analog inputs on the extensions of a basic unit
