Advant Controller AC 31 / Issued: 01.99 5 – 17 Programming
3
Bus response times:
Communications times of the CS31 system bus
Basic times for the master basic unit
2000 µs
Slave basic units without extensions
07 KR 51*
750 µs
07 KT 51*
750 µs
07 KR 91*
750 µs
07 KT 92*
750 µs
07 KT 93*
750 µs
07 KT 94*
* with default configuration
Times in accordance with the configuration
2 bytes for transmission and
2 bytes for receive
516 µs
4 bytes for transmission and
4 byte for receive
750 µs
8 bytes for transmission and
8 bytes for receive
1300 µs
12 bytes for transmission and
12 bytes for receive
1850 µs
8 words for transmission and
8 words for receive
2500 µs
Remote units with digital inputs
ICSI 08 D1
323 µs
ICSI 08 E1
323 µs
ICSI 08 E3/E4
323 µs
ICSI 16 D1
387 µs
ICSI 16 E1
387 µs
Remote output units
ICSO 08 R1
260 µs
ICSO 08 Y1
260 µs
ICSO 16 N1
340 µs
07 DI 92
516 µs
Remote units with inputs/outputs
ICSC 08 L1
387 µs
ICFC 16 L1
516 µs
ICSK 20 F1
452 µs
ICSK 20 N1
452 µs
07 DC 91
516 to 590 µs depending on the configuration
07 DC 92
517 to 750 µs depending on the configuration
