The IonicRF™ Generator Pole Mount (Model RF-POLE) is an accessory designed to facilitate the mounting of the IonicRF™ generator (Model RFG-IONIC) onto a compatible roll stand (Model RD-0856). This bracket provides a secure method for integrating the generator into a mobile setup, enhancing its portability and usability in various clinical environments. The primary function of the pole mount is to securely attach the generator to an equipment pole, ensuring stability during use and transport.

Function Description:

The IonicRF™ Generator Pole Mount serves as an interface between the IonicRF™ generator and a roll stand. It is specifically designed to hold the generator firmly in place, preventing accidental falls or dislodgement that could lead to injury or product damage. The mounting process involves attaching the pole mount to the roll stand, removing the generator's countertop stand, and then securing the generator to the pole mount. This modular design allows for flexible deployment of the IonicRF™ generator, adapting it from a countertop setup to a mobile, pole-mounted configuration as needed. The pole mount ensures that the generator remains at a safe and accessible height during procedures, contributing to an ergonomic and efficient workflow.

Important Technical Specifications:

Model: RF-POLE
Compatibility:
- IonicRF™ Generator: Model RFG-IONIC
- Roll Stand: Model RD-0856
Mounting Mechanism: Clamp-based system with captive thumb screws and cap-head screws for secure attachment.
Height Restriction (Generator Top): When installed, the top of the generator must not exceed 139.7 cm (55 inches) from the floor. This ensures compliance with safety guidelines and maintains optimal visibility and accessibility for the user.
Pole Mount Clamp Placement: The top of the pole mount clamp should be at least 1.2 cm (0.5 inches) below the bottom edge of the black pole cap of the roll stand. This specific placement is crucial for proper installation and stability.
Roll Stand Tray Load Limit: Do not place any items exceeding 4.4 pounds (2 kilograms) on the roll stand tray. This precaution prevents overloading and potential instability of the entire setup.
Assembly Requirement: Requires two people for safe assembly of both the roll stand and the generator to the pole mount. This is a critical safety measure to prevent the product from falling and causing injury or damage.

Usage Features:

Enhanced Portability: By mounting the generator on a roll stand, the system becomes mobile, allowing for easy relocation within a clinical setting. This is particularly beneficial in dynamic environments where the generator needs to be moved between different procedure rooms or patient areas.
Secure Attachment: The design incorporates captive thumb screws and cap-head screws to ensure a robust and stable connection between the generator, the pole mount, and the roll stand. This minimizes the risk of the generator falling during transport or use.
Ergonomic Positioning: The ability to adjust the height of the generator on the pole allows clinicians to position the device at an optimal working height, reducing strain and improving comfort during procedures. The specified maximum height of 139.7 cm (55 inches) from the floor guides this ergonomic placement.
Clear Installation Steps: The manual provides a detailed, step-by-step guide for installation, including locking roll stand wheels, sliding the pole mount onto the pole, tightening screws, and attaching the generator. This clarity helps ensure correct and safe setup.
Countertop Stand Removal: The process includes instructions for removing the generator's pre-attached countertop stand, preparing it for pole mounting. This highlights the versatility of the generator to be used in different configurations.
Two-Person Assembly: Emphasizing the need for two people for assembly underscores a key safety feature, ensuring that the generator is held steady while being attached, preventing drops and potential damage or injury.
Cable Management Consideration: Users are advised to ensure that any cables attached to the generator do not become entangled or present a tripping hazard when moving the roll stand. This promotes a safer working environment.

Maintenance Features:

Cleaning Guidelines: The pole mount can be cleaned using a cotton cloth soaked with 99% isopropyl alcohol or Sani-Cloth‡ AF3 germicidal disposable wipes. These cleaning agents are commonly available in clinical settings and are effective for maintaining hygiene without damaging the device.
Separate Cleaning Instructions for Generator/Roll Stand: The manual directs users to refer to the specific instructions for use for the generator and roll stand for their respective cleaning procedures. This ensures that each component receives appropriate care according to its material and design.
Durable Construction: While not explicitly detailed, the use of robust materials and secure fastening mechanisms implies a design intended for durability and longevity in a demanding clinical environment, reducing the frequency of maintenance or replacement.
Incident Reporting: The manual includes clear instructions for reporting serious incidents to the manufacturer or, for EU customers, to their national authority. This is a crucial aspect of post-market surveillance and continuous product improvement, ensuring that any issues are addressed promptly.
Technical Support Information: Contact details for technical support (toll-free number for North America and a direct line) are provided, allowing users to easily access assistance for questions or issues related to the product. This facilitates troubleshooting and ensures operational continuity.
Warranty Information: Users are directed to product packaging and commercial agreements for specific warranty details, ensuring they have access to information regarding product coverage and support.

In summary, the IonicRF™ Generator Pole Mount is a well-designed accessory that enhances the functionality and mobility of the IonicRF™ generator. Its robust construction, clear installation instructions, and emphasis on safety precautions make it a reliable component for clinical use, while its maintenance guidelines ensure ease of care and longevity.
