Section 4 Performance Characteristics and Specifications
Abbott VP 2000™ Processor Operations Manual Addendum Version 2 4-1
30-602111/R1—June 2010
Section 4: Performance Characteristics and Specifications
Performance Characteristics
and Specifications
Technical Data
Electrical Requirements
NOTE: UL has only tested the 117 VAC, 6 Amp, 60 Hz
unit, and this unit should be supplied from 117 VAC
+ 10% mains line voltage.
Table 4.1: Instrument Electrical Specifications
Rating
117 VAC: 6 Amps
110 VAC: 8 Amps
230 VAC: 4 Amps
Change Frequency
117 VAC: 60 Hz
100 VAC: 50/60 Hz
230 VAC: 50/60 Hz
Grounding
correctly grounded electrical outlet
Line voltage
117 VAC: 117 Volts +
10%
100 VAC: 100 Volts +
10%
230 VAC: 230 Volts +
10%
Electrical outlets, number
Minimum of 4 electrical outlets:
•instrument
•computer (CPU)
•monitor
• printer (optional)
• carbon filter system (optional)
