ABC Hobby Grid User Manual

2
1KN
䎃
18T Bevel Gear 10T Bevel Gear
Bevel
Cross Pin
5 x 0.3 mm Spacer
3.5 x 0.2 mm spacer
M4 O-ring
2.0 x 9 mm Pin
3 x 4 mm
Button Screw
3 x 8 mm
Button Screw
Counter Gear Shaft
1.6 x 0.8 mm Pin
20T Counter Gear
(48 Pitch)
25T Counter Gear
(48 Pitch)
1.6 x 0.8 mm Pin
Spur Gear Shaft
850 Bearing
3 x 8 mm Flat Head
Screw
Upper Mount Holder
Steering Holder
Diff Outer Joint
2.0 x 9 mm Pin
2 x 8 mm Tapping Screw
Diff Cover
Diff Rubber Pad
2.0 x 9 mm Pin
M4 O Ring
5 x 0.3 mm Spacer
3.5 x 0.2 mm
spacer
M4 O Ring
850 Bearing
850 Bearing
Bevel Cross Pin
Counter Gear Shaft
Diff Gear Box A
Diff Gear Box B
48T Diff Gear
3 x 8 mm Button Screw
Make sure that the gears are
in the right drive orientation.
Make sure that the gears are
in the right drive orientation.
10T Bevel Gear
18T Bevel Gear
2 x 8 mm
Tapping
Screw
Diff Cover
Diff
Rubber Pad
48T
Diff Gear
Tighten the screw equally
Counter Gear Shaft
1.6 x 0.8 mm Pin
20T Counter Gear
3 x 4 mm Button Screw
Diff Gear Box A
1510 Bearing
1510 Bearing
3 x 8 mm
Button Screw
Upper
Mount
Holder
3 x 8 mm
Button Screw
Motor Plate Holder
850
Bearing
850
Bearing
50T/25T
Spur Gear
3 x 4 mm
Button
Screw
25T
Counter Gear
1.6 x 0.8 mm Pin
Spur Gear Shaft
3 x 8 mm Flat
Head Screw
AL Motor Plate A
AL Motor Plate B
AL Motor Plate A
Upper
Mount
Holder
Upper
Mount
Holder
3 x 8 mm
Button Screw
3 x 8 mm
Button Screw
3 x 8 mm
Button Screw
Steering Holder
3 x 8 mm
Button Screw




GEAR BOX
1
2
MOTOR MOUNT
