ABC Hobby Grid User Manual

6
䟙䎔䎑䎓䏐䏐
䟙䎔䎑䎘䏐䏐
Rear
Front
Rear
Front
2.5mm Hex Wrench
2.5mm Hex Wrench
3 x 8 mm Button Screw
3 x 8 mm
Button Screw
3 x 8 mm
Button Screw
3 x 8 mm
Button Screw
Body Mount A
Body Mount C
Body Mount B
Body Mount A
Body Mount C
Body Mount B
Body Mount B
Extension Plate
Front
Rear
Front
Rear
When you use TAMIYA
body, use Body Mount B in
the Front, in combination
with extension plate and
Body Mount A in the rear.
After chassis completion,
adjust it again.
䎩䏕䏒䏑䏗
10
HUB CARRIER INSTALLATION
9
BODY MOUNT
