A-80 UHF SERVICE MANUAL
- 18 -
96 1UF 0805
Y5V,＋80%－
20%,25V
2 C226 C13
97 NC 0402 4 C220 C318 C334 C424
98 NC 0603 1 C155
Adjustable
capacitance
99 6PF φ2 TZVY2Z060A110T00 3 TC100 TC101 TC301
100 10PF φ2 TZVY2Z100A001R00 1 TC300
Tan capacitance
101 0.68UF A type
±20% 16V
1 C114
102 3.3UF A type
±20% 16V
1 C140
103 4.7UF A type
±20% 10V
3 C138 C152 C308
104 10UF A type ±20% 6.3V 3 C15 C357 C436
105 100UF C type ±20% 6.3V 1 C24
Inductor
106
BLM11A601S
BLM18AG601SN1D
0603 Bead 600R 7
L106 L110 L114 L117 L212
L300 L302
107 BLM21PG300SN1D 0805 Bead 1 L6
108
MGLB2012-011T
0805
CHIP CORE
2
L208 L209
109 LQG15HN2N2J02D 0402
HF Multi layer
Inductor
1 L201
110 LQG15HN15NJ02D 0402
HF Multi layer
Inductor
1 L210
111 LQG15HN18NJ02D 0402
HF Multi layer
Inductor
2 L100 L211
112 LQG15HN22NJ02D 0402
HF Multi layer
Inductor
3 L105 L115 L306
113 LQW31HN27NJ03L 1206 HF wound inductor 1 L103
114 LQW31HN33NJ03L 1206 HF wound inductor 1 L109
115 LQG15HN39NJ02D 0402
HF Multi layer
Inductor
1 L113
116 LQG15HNR10J02D 0402
HF Multi layer
Inductor
3 L303 L107 L108
117 MLG1608BR10J 0603
HF Multi layer
Inductor
1 L111
118 MLF1608A1R0K 0603
HF Multi layer
Inductor
2 L313 L314
