A-80 UHF SERVICE MANUAL
- 19 -
119 NLV25T-R56J-PF 2520 HF wound inductor 2 L305 L203
120 NLV25T-1R0J-PF 2520 HF wound inductor 1 L200
121 MLF1608A3R3K 0603
HF Multi layer
Inductor
5 R120 L101 L102 L104 L112
122 LFLK21254R7K 0805
HF Multi layer
Inductor
1 L118
123 0.4×φ1.6×3TR P type
AIR-CORE COIL with
Pin "E”
4 L307 L308 L310 L311
124 0.4×φ1.6×4TR P type
AIR-CORE COIL with
Pin "E”
4 L204 L205 L206 L309
125 0.4×φ1.8×4TR P type
AIR-CORE COIL with
Pin "E”
1
L304
126 0.4×φ1.6×5TR P type
AIR-CORE COIL with
Pin "E”
0
127 0.4×φ1.6×7TR P type
AIR-CORE COIL with
Pin "E”
1 L202
128
NC
0402 1 L116
Diode
129 HSC277 SOD-523 DIODE 4 D201 D300 D301 D302
130 HVC350B SOD-523 Varactor 5 D303 D304 D305 D306 D307
131 HVU131 SOD-323-A DIODE 1 D200
132 ISR154-400 SOD-106 DIODE 1 D2
133 ISV269 SOD-323-A Varactor 1 D104
134 ISV270 SOD-323-A Varactor 4 D100 D101 D102 D103
135 MA2S111 SOD-523 DIODE 2 D105 D107
Triode
136 2SA1362 SOT-23 TRANSISTOR 2 Q4 Q9
137 2SC2714 SOT-23 TRANSISTOR 1 Q302
138 2SC4226(R24) SOT-323 TRANSISTOR 5 Q100 Q101 Q102 Q103 Q205
139 2SC4617 SOT-416 TRANSISTOR 3 Q107 Q405 Q406
140 2SC4988 SOT-89-3L TRANSISTOR 1 Q204
141 2SK1824 SOT-416 FET 1 Q404
142 2SK508NV(K52) SOT-23 FET 1 Q104
143 AO3400 SOT-23 FET 1 Q6
144 3SK318 SOT-343 FET 2 Q300 Q301
145 DTA114EE SOT-416 TRANSISTOR 1 Q311
146 DTA114YE SOT-416 TRANSISTOR 1 Q303
147 DTA143TE SOT-416 TRANSISTOR 2 Q105 Q106
148 DTC114EE SOT-416 TRANSISTOR 3 Q5 Q7 Q8
