A-80 UHF SERVICE MANUAL
- 20 -
149 2SK3475 SOT89-3L FET 1 Q200
150 2SK3476 2-5N1A FET 1 Q201
IC
151 TA7368F SOP10
AUDIO POWER
AMP
1 IC2
152 TA31136FN
TSOP16 IF SYSTEM
1 IC300
153 MB1511PFV SSOP20 PLL 1
IC100
154 NJM2902-A SSOP14 AUDIO AMP 1
IC401
Crystal
155 12.8MHZ 3.2×5mm NT5032S 1 X100
Touch-key
156 TSHW-2VSL 7×2.5mm 2 S1 S2
PCB（A-80 UHF
V01）
PSW 1.0 V01
-072407
UHF
1
A-80（D47）A BOM
Ref.
No.
Specification Package Description Quantity Part. No.
Chip Resistor
1 0R 0402 ±5% 1 R244
2 0R 0603 ±5% 4 R24 R26 R27 R28
3 0.39R 1206 ±5% 3 R236 R237 R238
4 10R 0603 ±5% 1 R1
5 100R 0603 ±5% 1 R449
6 330R 0603 ±5% 3 R5 R6 R16
7 390R 0603 ±5% 1 R253
8 470R 0603 ±5% 1 R413
9 680R 0402 ±5% 2 R232 R233
10 820R 0603 ±5% 1 R424
11 1K 0603 ±5% 10
R7 R8 R12 R17 R22 R30
R32 R34 R48 R401
12 1.5K 0603 ±5% 1 R421
13 2K 0603 ±5% 1 R420
14 2.2K 0603 ±5% 2 R60 R419
15 3.3K 0603 ±5% 2 R252 R402
16 4.7K 0603 ±5% 7
R11 R13 R14 R15 R39
R54 R61
17 5.6K 0603 ±5% 2 R247 R415
