A-80 UHF SERVICE MANUAL
- 27 -
Adjustable capacitance
99 6PF φ2 TZVY2Z060A110T00 3 TC100 TC101 TC301
100 10PF φ2 TZVY2Z100A001R00 1 TC300
Tan capacitance
101 0.68UF A type
±20% 16V
1 C114
102 3.3UF A type
±20% 16V
1 C140
103 4.7UF A type
±20% 10V
3 C138 C152 C308
104 10UF A type ±20% 6.3V 3 C15 C357 C436
105 100UF C type ±20% 6.3V 1 C24
Inductor
105
BLM11A601S
BLM18AG601SN1D
0603 Bead 600R 7
L106 L110 L114 L117
L212 L300 L302
106 BLM21PG300SN1D 0805 Bead 1 L6
107
MGLB2012-011T
0805
CHIP CORE
2
L208 L209
108 LQG15HN1N8J02D 0402
HF Multi layer
Inductor
1 L201
109 LQG15HN15NJ02D 0402
HF Multi layer
Inductor
1 L210
110 LQG15HN18NJ02D 0402
HF Multi layer
Inductor
2 L100 L211
111 LQG15HN22NJ02D 0402
HF Multi layer
Inductor
3 L105 L115 L306
112 LQW31HN23NJ03L 1206 HF wound inductor 1 L103
113 LQW31HN27NJ03L 1206 HF wound inductor 1 L109
114 LQG15HN39NJ02D 0402
HF Multi layer
Inductor
1 L113
115 LQG15HNR10J02D 0402
HF Multi layer
Inductor
2 L303 L107
116 MLG1608BR10J 0603
HF Multi layer
Inductor
1 L111
117 MLF1608A1R0K 0603
LF Multi layer
Inductor
2 L313 L314
118 NLV25T-R56J-PF 2520 HF wound inductor 2 L305 L203
119 NLV25T-1R0J-PF 2520 HF wound inductor 1 L200
120 MLF1608A3R3K 0603
LF Multi layer
Inductor
5
R120 L101 L102 L104
L112
121 LFLK21254R7K 0805
LF Multi layer
Inductor
1 L118
122 0.4×φ1.6×3TR P type
AIR-CORE COIL with
pin "E”
8
L204 L205 L206 L307 L308
L309 L310 L311
123 0.4×φ1.6×4TR P type
AIR-CORE COIL with
pin "E”
0
