124 0.4×φ1.8×4TR P type
AIR-CORE COIL with
pin "E”
1
L304
125 0.4×φ1.6×5TR P type
AIR-CORE COIL with
pin "E”
0
126 0.4×φ1.6×7TR P type
AIR-CORE COIL with
pin "E”
1 L202
127
NC
0402 1 L116
Diode
128 HSC277 SOD-523 DIODE 4 D201 D300 D301 D302
129 HVC350B SOD-523 Varactor 5 D303 D304 D305 D306 D307
130 HVU131 SOD-323-A DIODE 1 D200
131 ISR154-400 SOD-106 DIODE 1 D2
132 ISV269 SOD-323-A Varactor 1 D104
133 ISV270 SOD-323-A Varactor 4 D100 D101 D102 D103
134 MA2S111 SOD-523 DIODE 2 D105 D107
Triode
135 2SA1362 SOT-23 TRANSISTOR 2 Q4 Q9
136 2SC2714 SOT-23 TRANSISTOR 1 Q302
137 2SC4226(R24) SOT-323 TRANSISTOR 5 Q100 Q101 Q102 Q103 Q205
138 2SC4617 SOT-416 TRANSISTOR 3 Q107 Q405 Q406
139 2SC4988 SOT-89-3L TRANSISTOR 1 Q204
140 2SK1824 SOT-416 FET 1 Q404
141 2SK508NV(K52) SOT-23 FET 1 Q104
142 AO3400 SOT-23 FET 1 Q6
143 3SK318 SOT-343 FET 2 Q300 Q301
144 DTA114EE SOT-416 TRANSISTOR 1 Q311
145 DTA114YE SOT-416 TRANSISTOR 1 Q303
146 DTA143TE SOT-416 TRANSISTOR 2 Q105 Q106
147 DTC114EE SOT-416 TRANSISTOR 3 Q5 Q7 Q8
148 2SK3475 SOT89-3L FET 1 Q200
149 2SK3476 2-5N1A FET 1 Q201
IC
150 TA7368F SOP10
AUDIO POWER
AMP
1 IC2
151 TA31136FN
TSOP16 IF SYSTEM
1 IC300
152 MB1511PFV SSOP20 PLL 1
IC100
153 NJM2902-A SSOP14 AUDIO AMP 1
IC401
154 Crystal
155 12.8MHZ 3.2×5mm NT5032S 1 X100
Touch-Key
156 TSHW-2VSL 7×2.5mm 2 S1 S2
