Abell S1 - Page 17

S1 Service manual
17
47 10PF 0402
COG，±5%，16V
4 C6 C114 C115 C162
48 12PF 0402
COG，±5%，16V
2 C116 C125
49 18PF 0603
COG，±5%，16V
1 C78
50 20PF 0402
COG，±5%，16V
1 C50
51 27PF 0603
COG，±5%，16V
1 C71
52 39PF 0402
COG，±5%，16V
1 C121
53 47PF 0402
COG，±5%，16V
2 C138 C149
54 100PF 0402
COG，±5%，16V
4 C108 C127 C168 C169
55 470PF 0402
X7R，±10%，16V
16
C32 C51 C52 C56 C79 C81 C110
C111 C122 C126 C144 C155 C160
C171 C172 C177
56 1000PF 0402
X7R，±10%，16V
18
C28 C29 C35 C42 C43 C44 C45
C46 C47 C48 C83 C84 C92 C105
C147 C157 C158 C165
57 1000PF 0603
X7R，±10%，16V
1 C148
58 0.01UF 0402
X7R，±10%，16V
4 C31 C34 C146 C180
59 0.047UF 0402
X7R，±10%，16V
1 C97
60 0.1UF 0402
X7R，±10%，16V
15
C5 C10 C16 C18 C20 C21 C30 C41
C95 C102 C103 C104 C117 C123
C132
61 0.1UF 0805
X7R，±10%，16V
1 C175
62 0.33UF 0603
X7R，±10%，16V
1 C181
63 0.47UF 0402
X5R，±10%，6.3V
1 C178
64 1UF 0402 Y5V, +80,-20%,10V 1 C33
65 1UF 0805 Y5V, +80,-20%,16V 1 C107
66 10UF 0805
X5R，±10%，10V
1 C26
67 NC 0805 NC C143
68 NC 0603 NC RTH1
69 NC 0402 NC
C8 C68 C69 C73 C74 C80 C96
C100 C101 C106 C109 C112 C130
C133 C193 R84 R96 R100 R111
R112
Tan- Capacitor
70 2.2UF
A 型
±20% 10V 1 C98
Adjustable
Capacitor
71 6PF φ3
TZC03Z060A110T00
ECRKN006A61X
2 TC1 TC2
Inductor
72 BLM18AG601SN1D 0603 Bead 600R 4 L7 L8 L11 L29
73 MGLB2012-011B 0805 Bead 1 L9
74 BLM21PG300SN1DS 0805 Bead 1 L35
75 LQG15HN2N2S02D 0402 HF Multi-layer inductor 1 L17
