S1 Service manual
18
76
LQG15HN6N8J02
MLK1005S6N8J
0402 HF Multi-layer inductor 1 L14
77 LQG15HN18NJ02 0402 HF Multi-layer inductor 1 L10
78 LGQ18HN22NJ00 0603 HF Multi-layer inductor 1 L23
79
LQG15HN22NJ02D
MLK1005S22NJ
0402 HF Multi-layer inductor 1 L15
80
LQG15HN39NJ02D
MLK1005S39NJ00D
0402 HF Multi-layer inductor 2 L16 L34
81 LQG15HNR12J00D 0402 HF Multi-layer conductor 1 R110
82 NLV25T-R22J-PF 2520 Wired conductor 1 L22
83 NLV25T-1R0T-PF 2520 Wired conductor 1 L18
84 NLV25T-2R2T-PF 2520 Wired conductor 1 L12
85 MLF1608A3R3KT000 0603 LF Multi-layer conductor 1 L28
86 MLF1608A4R7KT 0603 LF Multi-layer conductor 1 L1
87 0.3×1.5×2.5T P type
AIR-CORE COIL with
pin“E"
7 L2 L21 L24 L25 L26 L27 L33
88 0.3×1.5×3.5T P type
AIR-CORE COIL with
pin“E"
4 L3 L4 L30 L31
89 0.3×1.5×5.5T P type
AIR-CORE COIL with
pin“E""
1 L13
90 0.3×1.5×6.5T P type
AIR-CORE COIL with pin
“E"
1 L19
Diode
91 HSC277 SOD-523 DIODE 4 D4 D5 D6 D8
92 HVC131TRF SOD-523 DIODE 1 D12
93 HVC350B SOD-523 Varactor Diode 5 VD1 VD3 D3 D13 D14
94 1SV214 SOD-323-A Varactor Diode 1 VD2
95 MA2S11100L SOD-523 DIODE 4 D2 D9 D10 D11
96 NC D0402 NC D7
Triode
97 FMMT717 SOT-23 TRANSISTOR 1 Q13
98 2SC1623 SOT-23 TRANSISTOR 1 Q7
99 2SC2714 SOT-23 TRANSISTOR 1 Q23
100 2SC4226(R24) SOT-323 TRANSISTOR 2 Q10 Q14
101 2SC4738-GR SOT-416 TRANSISTOR 1 Q20
102 2SC5066 SOT-323 TRANSISTOR 1 Q8
103 2SC5108 SOT-416 TRANSISTOR 1 Q9
104 2SK3078 SOT-89-3L FET 1 Q18
105 2SK3476 2-5N1A FET 1 Q29
106 DTA123JE SOT-416 TRANSISTOR 3 Q1 Q3 Q11
107 DTC114EE SOT-416 TRANSISTOR 1 Q6
108 DTC144EE SOT-416 TRANSISTOR 1 Q4
