Abell S1 - Page 19

S1 Service manual
19
109 BF998R SOT-143R FET 2 Q2 Q12
IC
110 MC3361 SOP-16 IF SYSTEM 1 IC7
111 TDA2822 SOP8 AF Amplifier 1 IC6
112 XC6219B302M SOT-25 3V stabilized voltage IC 1 IC3
113 GP214D TSOP16 PLL IC 1 IC4
Crystal
114 13.0000MHZ 3.2×5mm DSA535SA 1 X1
115
PCB
(TH308K V03)
PSW V3.0 V03
09-19-05
UHF
1
Version：1.0
S1 (D57) A side BOM
Ref.
No.
Specification Packing Description Quantity Part No.
Chip Resistor
1 0R 0402 ±5% 9
C55 C153 R4 R15 R25 R30 R31
R74 R85
2 10R 0402 ±5% 1 R11
3 100R 0402 ±5% 1 R116
4 150R 0402 ±5% 1 C136
5 1K 0402 ±5% 11
R2 R19 R26 R48 R49 R101
R106 R114 R115 R134 R136
6 2.2K 0402 ±5% 1 R18
7 4.7K 0402 ±5% 2 R82 R121
8 5.6K 0402 ±5% 1 R3
9 10K 0402 ±5% 7 R1 R5 R32 R40 R41 R92 R118
10 15K 0402 ±5% 1 C93
11 22K 0402 ±5% 1 C3
12 47K 0402 ±5% 3 R23 R43 R70
13 100K 0402 ±5% 7 R6 R7 R9 R10 R24 R44 R47
14 150K 0402 ±5% 1 R22
15 330K 0402 ±5% 1 R14
Resistor Network
16 1K×4 4×0603 YC164-JR-071K 1 R45
Adjustable
Resistor
17 68K Φ3 EVM3YSX50BS4 1 VR2
Chip Capacitor
