Abell S1 - Page 20

S1 Service manual
20
18 22PF 0402
COG，±5%，16V
2 C134 C135
19 220PF 0402
X7R，±10%，16V
1 C151
20 470PF 0402
X7R，±10%，16V
8
C22 C23 C24 C25 C128 C166
C167 C183
21 1000PF 0402
X7R，±10%，16V
4 C19 C60 C91 C145
22 3900PF 0402
X7R，±10%，16V
1 C87
23 0.01UF 0402
X7R，±10%，16V
1 C131
24 0.022UF 0402
X7R，±10%，16V
2 C1 C2
25 0.033UF 0402
X7R，±10%，16V
1 C141
26 0.1UF 0402
X7R，±10%，16V
11
C7 C9 C11 C12 C14 C15 C17
C53 C85 C124 C150
27 1UF 0402 Y5V, +80,-20%,10V 1 C164
28 1UF 0603 Y5V, +80,-20%,16V 1 C182
29 10UF 0805
X5R，±10%，10V
1 C4
30 NC 0402 NC
C49 C54 C61 C90 C94 C163
C191 R46 R57 R72 R108 R109
Tan Capacitor
31 1UF
A 型
±20% 16V 2 C99 C142
Inductor
32 BLM18AG601SN1D 0603 0603 Bead 600R 2 L6 L32
33 NC 1010 NC L5
Diode
34 LED-02-0603 QGC D0603 Green LED 1 LED3
35 LED-02-0603 QRC D0603 Red LED 1 LED4
36 NC D0603 NC D1
Triode
37 DTC114EE SOT-416 TRANSISTOR 1 Q17
38 DTC114TE SOT-416 TRANSISTOR 1 Q16
IC
39 PST9128NR SOT-25 Restoration IC 1 IC2
40 AT24C08BN-SH SOP8 EEPROM 1 IC1
41
SRT3210
(CS:331DF98B
V1.2)
SSOP100
IC320QUAD100 CPU after
writing
1 IC5
Crystal
42 32.768KHz 8.0×3.8mm CM200C 12.5PF/+ -30PPM 1 Y1
Version：1.0
S1 (D57) B Side BOM
Ref. Specification Packing Description Quantity Part No.
