Abell S1 - Page 23

S1 Service manual
23
70 2.2UF A Type ±20% 10V 1 C98
Adjustable
Capacitor
71 6PF φ3
TZC03Z060A110T00
ECRKN006A61X
2 TC1 TC2
Inductor
72 BLM18AG601SN1D 0603 Bead 600R 4 L7 L8 L11 L29
73 MGLB2012-011B 0805 Bead 1 L9
74 BLM21PG300SN1DS 0805 Bead 1 L35
75 LQG15HN2N2S02D 0402 HF Multi-Layer inductor 2 L10 L17
76
LQG15HN6N8J02
MLK1005S6N8J
0402 HF Multi-Layer inductor 1 L14
77 LGQ18HN22NJ00 0603 HF Multi-Layer inductor 1 L23
78
LQG15HN22NJ02D
MLK1005S22NJ
0402 HF Multi-Layer inductor 2 L15 L16
79
LQG15HN39NJ02D
MLK1005S39NJ00D
0402 HF Multi-Layer inductor 1 L34
80 LQG15HNR12J00D 0402 HF Multi-Layer inductor 1 R110
81 NLV25T-R22J-PF 2520 Wired inductor 1 L22
82 NLV25T-1R0T-PF 2520 Wired inductor 1 L18
83 NLV25T-2R2T-PF 2520 Wired inductor 1 L12
84 MLF1608A3R3KT000 0603 LF Multi-Layer inductor 1 L28
85 MLF1608A4R7KT 0603 LF Multi-Layer inductor 1 L1
86 0.3×1.5×2.5T
P 型
AIR-CORE COIL with pin“E" 7 L2 L21 L24 L25 L26 L27 L33
87 0.3×1.5×3.5T
P 型
AIR-CORE COIL with pin “E" 4 L3 L4 L30 L31
88 0.3×1.5×4.5T
P 型
AIR-CORE COIL with pin “E" 1 L13
89 0.3×1.5×6.5T
P 型
AIR-CORE COIL with pin “E" 1 L19
Diode
90 HSC277 SOD-523 DIODE 4 D4 D5 D6 D8
91 HVC131TRF SOD-523 DIODE 1 D12
92 HVC350B SOD-523 Varactor Diode 5 VD1 VD3 D3 D13 D14
93 1SV214 SOD-323-A Varactor Diode 1 VD2
94 MA2S11100L SOD-523 DIODE 4 D2 D9 D10 D11
95 NC D0402 NC D7
Triode
96 FMMT717 SOT-23 TRANSISTOR 1 Q13
97 2SC1623 SOT-23 TRANSISTOR 1 Q7
98 2SC2714 SOT-23 TRANSISTOR 1 Q23
99 2SC4226(R24) SOT-323 TRANSISTOR 2 Q10 Q14
100 2SC4738-GR SOT-416 TRANSISTOR 1 Q20
101 2SC5066 SOT-323 TRANSISTOR 1 Q8
102 2SC5108 SOT-416 TRANSISTOR 1 Q9
103 2SK3078 SOT-89-3L FET 1 Q18
