104 2SK3476 2-5N1A FET 1 Q29
105 DTA123JE SOT-416 TRANSISTOR 3 Q1 Q3 Q11
106 DTC114EE SOT-416 TRANSISTOR 1 Q6
107 DTC144EE SOT-416 TRANSISTOR 1 Q4
108 BF998R SOT-143R FET 2 Q2 Q12
IC
109 MC3361 SOP-16 IF SYSTEM 1 IC7
110 TDA2822 SOP8 AF Amplifier 1 IC6
111 XC6219B302M SOT-25 3V stabilized voltage IC 1 IC3
112 GP214D TSOP16 PLL IC 1 IC4
Crystal
113 13.0000MHZ 3.2×5mm DSA535SA 1 X1
114
PCB
(TH308K V03)
PSW V3.0 V03
09-19-05
UHF
1
S1 446MHz A Side BOM
Ref.
NO.
Specification Packing Description Quantity Part. No.
Chip Resistor
1 0R 0402 ±5% 10
C55,C153,R4,R15,
R25,R31,R48,R74,R85,R121
2 10R 0402 ±5% 1 R11
3 100R 0402 ±5% 1 R116
4 150R 0402 ±5% 1 C136
5 1K 0402 ±5% 10
R2,R19,R26,R49,R101,R106,R114,R
115, R134,R136
6 2.2K 0402 ±5% 1 R18
7 4.7K 0402 ±5% 1 R82
8 5.6K 0402 ±5% 1 R3
9 10K 0402 ±5% 7 R1,R5,R32,R40,R41,R92,R118
10 15K 0402 ±5% 1 C93
11 22K 0402 ±5% 1 C3
12 47K 0402 ±5% 3 R23,R43,R70
13 100K 0402 ±5% 5 R6,R7,R14,R24,R44
14 120K 0402 ±1% 1 R10
15 150K 0402 ±5% 2 R22,R47
16 150K 0402 ±1% 1 R9
