S1 Service manual
26
43 32.768KHz 8.0×3.8mm
CM200C 12.5PF/+
-30PPM
1 Y1
S1 446MHz B Side BOM
Ref.
No.
Specification Packing Description Quantity Part No.
Chip Resistor
1 0R 0402 ±5% 7
C59,C140,L20,R27,R42,R102,R1
20
2 0R 0603 ±5% 1 R140
3 0R 0805 ±5% 1 L45
4 10R 0402 ±5% 7
R12,R13,R33,R35,R124,
R126,R128
5 22R 0402 ±5% 2 R34,R127
6 47R 0402 ±5% 1 R137
7 100R 0402 ±5% 4 R16,R71,R86,R87
8 150R 0402 ±5% 1 R105
9 220R 0402 ±5% 3 R80,R81,R139
10 270R 0402 ±5% 2 R54,R67
11 820R 0402 ±5% 1 R28
12 1K 0402 ±5% 4 R53,R55,R107,R122
13 1.2K 0402 ±5% 2 R50,R99
14 2K 0402 ±5% 1 R95
15 2.2K 0402 ±5% 5 R29,R37,R60,R77, R125
16 2.7K 0402 ±5% 1 R135
17 3.3K 0402 ±5% 3 R20,R58,R75
18 4.7K 0402 ±5% 5 R17,R52,R68,R78, R113
19 6.8K 0402 ±5% 2 R51,R76
20 8.2K 0402 ±5% 6 R21,R38,R61,R66, R69,R83
21 10K 0402 ±5% 3 R62,R79,R123
22 12K 0402 ±5% 1 R88
23 22K 0402 ±5% 1 R129
24 47K 0402 ±5% 7
R36,R56,R59,R89,R91,R133,C13
9
25 68K 0402 ±5% 1 R103
