Abell S1 - Page 27

S1 Service manual
27
26 82K 0402 ±5% 2 R90,R138
27 100K 0402 ±5% 6 R39,R64,R73,R97,R141, R142
28 120K 0402 ±5% 1 R8
29 220K 0402 ±5% 2 R98,R104
30 270K 0402 ±5% 1 R63
31 680K 0402 ±5% 1 R65
Resistor Network
32 1K×4 4×0603 YC164-JR-071K 1 R132
Chip Capacitor
33 0.5PF 0402 COG,±0.1PF,16V 3 C39,C129,C173
34 0.75PF 0402 COG,±0.1PF,16V 1 C57
35 1PF 0402 COG,±0.1PF,16V 1 C82
36 1PF 0603 COG,±0.1PF,16V 2 C86,C119
37 1.5PF 0402 COG,±0.1PF,16V 1 C159
38 2PF 0402 COG,±0.1PF,16V 5 C37,C62,C63,C89, C161
39 3PF 0402 COG,±0.1PF,16V 6 C13,C58,C88,C113,C170, C174
40 3PF 0603 COG,±0.1PF,16V 1 C72
41 4PF 0402 COG,±0.1PF,16V 4 C64,C67,C75,C156
42 5PF 0402 COG,±0.1PF,16V 4 C38,C40,C76,C77
43 6PF 0402 COG,±0.25PF,16V 2 C36,C65
44 7PF 0402 COG,±0.5PF,16V 2 C70,C125
45 10PF 0402 COG,±5%,16V 4 C6,C114,C115,C162
46 15PF 0402 COG,±5%,16V 1 C116
47 18PF 0603 COG,±5%,16V 1 C78
48 20PF 0402 COG,±5%,16V 1 C50
49 27PF 0603 COG,±5%,16V 1 C71
50 30PF 0402 COG,±5%,16V 3 C121,C138,C149
51 100PF 0402 COG,±5%,16V 4 C108,C127,C168,C169
52 470PF 0402 X7R,±10%,16V 16
C32,C51,C52,C56,
C79,C81,C110,C111,C122,C126,
C144, C155, C160,C171,C172,
C177
53 1000PF 0402 X7R,±10%,16V 18
C28,C29,C35,C42,
C43,C44,C45,C46,
C47,C48,C83,C84,
C92,C105,C147,
C157,C158,C165
54 1000PF 0603 X7R,±10%,16V 1 C148
55 0.01UF 0402 X7R,±10%,16V 4 C31,C34,C146,C180
