Abell S1 - Page 28

S1 Service manual
28
56 0.027UF 0402 X7R,±10%,16V 3 C68,C130,C133
57 0.047UF 0402 X7R,±10%,16V 1 C97
58 0.1UF 0402 X7R,±10%,16V 15
C5,C10,C16,C18,C20,C21,
C30,C41,
C95,C102,C103,C104,C117,
C123,C132
59 0.1UF 0805 X7R,±10%,16V 1 C175
60 0.33UF 0603 X7R,±10%,16V 1 C181
61 0.47UF 0402 X5R,±10%,6.3V 1 C178
62 1UF 0402 X5R,±10%,10V 1 C33
63 1UF 0805 Y5V,+80,-20%,16V 1 C107
64 10UF 0805 X5R,±10%,10V 1 C26
65 NC 0402 NC
C8,C66,C69,C73,
C74,C80,C96,C100,
C101,C106,C49,C109,C112,C154
,C193, R84,R96,R100,R111,R112
66 NC 0603 NC RTH1
67 NC 0805 NC C143
Tan-Capacitor
68 2.2UF A Type ±20% 10V 1 C98
69 100UF B Type ±20% 6.3V 1 C196
Adjustable
Capacitor
70 6PF φ3
TZC3Z060A110R00
ECRKN006A61X
2 TC1,TC2
Inductor
71 BLM18AG601SN1D 0603 Bead 600R 4 L7,L8,L11,L29
72 MGLB2012-011B 0805 Bead 1 L9
73 BLM21PG300SN1DS 0805 Bead 1 L35
74 LQG15HN2N2S02D 0402 HF Multi-Layer Inductor 1 L17
75 LQG15HS8N2J02D 0402 HF Multi-Layer Inductor 2 L14,L16
76
LQG15HN18NJ02
MLK1005S18NJ
0402 HF Multi-Layer Inductor 1 L10
77
LQG15HN22NJ02D
MLK1005S22NJ
0402 HF Multi-Layer Inductor 1 L15
78 LQG18HN22NJ00 0603 HF Multi-Layer Inductor 1 L23
79 MLK1005S27NJT00D 0402 HF Multi-Layer Inductor 1 L34
80 LQG15HNR12J00D 0402 HF Multi-Layer Inductor 1 R110
