S1 Service manual
29
81 NLV25T-R22J-PF 2520 Wired Inductor 1 L22
82 NLV25T-1R0T-PF 2520 Wired Inductor 1 L18
83 NLV25T-2R2T-PF 2520 Wired Inductor 1 L12
84 MLF1608A3R3KT000 0603 LF Multi-Layer Inductor 1 L28
85 MLF1608A4R7KT 0603 LF Multi-Layer Inductor 1 L1
86 0.3×1.5×2.5T P type
AIR-CORE COIL with pin“E"
7 L2,L21,L24,L25,L26,L27, L33
87 0.3×1.5×3.5T P Type
AIR-CORE COIL with pin “E"
4 L3,L4,L30,L31
88 0.3×1.5×4.5T P Type
AIR-CORE COIL with pin “E"
1 L13
89 0.3×1.5×6.5T P Type
AIR-CORE COIL with pin “E"
1 L19
Diode
90 HSC277 SOD-523 DIODE 4 D4,D5,D6,D8
91 HVC131TRF SOD-523 DIODE 1 D12
92 HVC350B SOD-523 Varactor diode 5 VD1,VD3,D3,D13,D14
93 1SV214 SOD-323-A Varactor diode 1 VD2
94 MA2S11100L SOD-523 DIODE 4 D2,D9,D10,D11
95 NC D0402 NC D7
Tiode
96 FMMT717 SOT-23 TRANSISTOR 1 Q13
97 2SC1623 SOT-23 TRANSISTOR 1 Q7
98 2SC2714 SOT-23 TRANSISTOR 1 Q23
99 2SC4226 SOT-323 TRANSISTOR 2 Q10,Q14
100 2SC4738-GR SOT-416 TRANSISTOR 1 Q20
101 2SC5066 SOT-323 TRANSISTOR 1 Q8
102 2SC5108 SOT-416 TRANSISTOR 1 Q9
103 2SK3078 SOT-89-3L FET 1 Q18
104 2SK3476 2-5N1A FET 1 Q29
105 DTA123JE SOT-416 TRANSISTOR 3 Q1,Q3,Q11
106 DTC114EE SOT-416 TRANSISTOR 1 Q6
107 DTC144EE SOT-416 TRANSISTOR 1 Q4
108 BF998R SOT-143R FET 2 Q2,Q12
IC
109 MC3361 SOP-16 IF SYSTEM 1 IC7
110 TDA2822 SOP8 AF Amplifier 1 IC6
111 XC6219B302M SOT-25 3V stabilized voltage IC 1 IC3
112 GP214D TSOP16 PLL IC 1 IC4
Crystal
113 13.0000MHZ 3.2×5mm DSA535SA 1 X1
114
PCB
(TH308K V04)
PSW V3.0 V04
09-37-02
UHF
1
