S1 Service manual
30
Version：1.0 S1 Assembly parts BOM
Part No. Material Specification Quanitty Description Model
F02308-032
TH308K(D02) half
products
1
Assembly：Plastic
parts
P01308-027 Front cabinet ABS 1 S1
P10308-009 Back cabinet ABS 1
P14308-009
Back cabinet
accessories
ABS 1
P09308-010 Battery cover ABS 1
P21308-004 Earphone jack cover ABS 1
P15308-004 Button ABS 1
P25308-002 Channel cover ABS 1
S1
P08308-003 Volume knob(S) ABS 1 TH308 Series
P07308-004 Channel knob(L) ABS 1 TH308 Series
P12308-003 Belt clip ABS 1 TH308 Series
P16308-002 Belt clip set ABS 1 TH308 Series
P04308-002 LED PC Transparence 1 LED TH308 Series
Rubber parts
:
L01308-006 PTT rubber button Rubber 1 TH308 Series
L02308-003 Speaker Rubber mat Rubber 1 TH308 Series
L02308-016 PTT rubber mat 8×5×3.0mm 1 TH308 Series
Single-sided glue
:
S07308-008
Speaker dustproof
vover
φ46.5×35×7.8mm 1
N-250#（Import
from USA）
TH308 Series
S02307-001
Speaker sponge
cushion
φ16×1（mm）
1 TH308 Series
S02307-003 Crystal sponge cushion 7×4×1(mm) 2 TH308 Series
S06307-006 Radiator silicon 7.5×6.5×1.0mm 1
2SK3476 (3M
paster)
TH307、TH308
Series ，
A80,A82 series
S02308-025
Battery cover sponge
cushion
33×10×2.0mm 1 S1
S02308-024
Battery lock sponge
cushion
9.5×6.5×1.5mm 1 S-1
T17308-003 PVC insulation 27×14.5×0.3mm 1
black，
PVC+3M9448HK
S-1
S02308-032
Battery tunnel sponge
cushion
17×5×1.0mm 1 S-1
Metal parts
:
