14
1 Open the cover 3 p. 15
A
Cover
B
Type plate
2 The type plate is located
under the cover
2. YOUR MODEL VARIANT
Type plate
Model variants
A
B

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ABL eMH1 WALLBOX and is the answer not in the manual?

ABL eMH1 WALLBOX Specifications

General IconGeneral
Charging ConnectorType 2
Cable Length5 m
InstallationWall-mounted
Protection ClassIP54
Housing MaterialPlastic
Charging Current16 A
Input Voltage230 V
