7. DISPLAY WINDOW
1 Open the cover 3 p. 51
4 p. 51
2 Locate the power meter in the central
display window. The display window is
located in the upper part of the housing
A
Cover
B
Upper part of housing
Illustration is
approximate
C
Display window
D
Power meter
A
B
C
D
