55
Temporary
Permanent
8. SHUTDOWN
Illustration is
approximate
B
A
3 Flick the pivot lever of the
internal RCCB to the 0 position.
Connection to the electricity grid
is now interrupted. The Wallbox
can no longer carry out charging
procedures
4 Close the cover
Tool:
Key
In the absence of an RCCB, the cir-
cuit breaker in the domestic power
distribution must be switched off
in order to take the Wallbox out of
operation temporarily or perma-
nently
A
Pivot lever
B
Cover
