10. TECHNICAL
SPECIFICATIONS
Model code 22 kW
1W2221 1W2201
Voltage
230 / 400 V 230 / 400 V
Grid frequency
50 Hz 50 Hz
Current
32 A 32 A
Charging output
22 kW 22 kW
Charging connection
Type 2 charging socket Type 2 charging cable (ca. 6m)
Phase system
3-phase 3-phase
Residual-Current Devices
RCCB, Type A, 30 mA RCCB, Type A, 30 mA
DC fault current detection
DC-RCM, In d.c. ≥ 6 mA DC-RCM, In d.c. ≥ 6 mA
EVCC
2 2
Compliance
IEC 61851-1 IEC 61851-1
Control / Customization
Internal RS485 interface Internal RS485 interface
Terminal block
up to 50 mm² up to 50 mm²
Operating temperature
-30°C to 50°C -30°C to 50°C
Storage temperature
-30°C to 85°C -30°C to 85°C
Rel. humidity
5 to 95% (no condensation) 5 to 95% (no condensation)
Class of protection
I I
Degree of protection (hous-
ing)
IP44 IP54
Overvoltage category
III III
Dimensions
272 x 221 x 116 mm (H x W x D) 272 x 221 x 116 mm (H x W x D)
Weight per unit
ca. 3 kg ca. 4.5 kg
