ABLE Ap1400 - Summary of Non-Volatile Settings

Ref: "Ap1400ProgGuide1_2.docx" Page 22 of 42
Document Revision: “1.2”
Document Date: “9 Apr. 2013”
Summary Of Non-Volatile Settings
Setting
How set
How
reported
Firmware Version No. GS,”I”,3 Also In Self Test
Unit Serial No. GS,”I”,6 Also In Self Test
Save all configuration to Flash ESC,"X",48
Auto-Save config to Flash (Period) ESC,"X",52.. GS,”I”,52
Baud Rate, Parity etc ESC,”X”,4.. GS,”I”,4 Also In Self Test
LED patterns & LED Flash Period ESC,”X”,18.. GS,”I”,18
Default to Inverted Print ESC,”X”,9.. GS,”I”,9 Also Coded In Self Test
Short Demo Message ESC,”X”,23.. Coded In Self Test
Suppress "?" on Rx Error ESC,”X”,9.. GS,”I”,9 Also Coded In Self Test
Split dots Printing (enable) ESC,”X”,9.. GS,”I”,9 Also Coded In Self Test
Split dots Printing (MaxDotsAtOnce) ESC,”X”,33.. GS,”I”,33 Also Coded In Self Test
Disable Feed Switch ESC,”c5”.. Coded In Self Test
Disable Demo Mode ESC,”c5”.. Coded In Self Test
Swap '#' (23H) <-> '£' (9CH) chars ESC,"X",23,n GS,"I",23
Use 'ø' & 'Ø' <-> '¢' (9BH) & '¥' (9DH) ESC,"X",23,n GS,"I",23
Use 'Ç' <-> '€' (80H) ESC,"X",23,n GS,"I",23
Enable Black Mark Operation ESC,”X”,19.. GS,”I”,19 Also Coded In Self Test
Black Mark parameters (detail) ESC,”X”,20.. GS,”I”,20
Black Mark parameters (more detail) ESC,”X”,42.. GS,”I”,42
Paper Out -> LED Pattern ESC,”X”,19.. GS,”I”,19 Also Coded In Self Test
Head Up -> LED Pattern ESC,”X”,19.. GS,”I”,19 Also Coded In Self Test
Select Busy on Paper Out condition ESC,"X",23,n GS,"I",23
Font Mode ESC,"!",n Also Coded In Self Test
Disable FontMode changes ESC,”X”,9.. GS,”I”,9 Also Coded In Self Test
AUTO_STATUS settings GS,”a”..
A simple Windows setup program is available from Able on request allowing a printer to be configured
via a suitable RS232 (or alternatively USB to RS232 converter) cable.
Please refer to Able Systems or visit our website at www.able-systems.com for more information.
