Abra A5 - Hardware Overview; Front View System Map; LED Indicators

10
EN
System Map: Front View with LCD Panel Open
LED Indicators
Figure 3 - Front View with LCD Panel Open
1. PC Camera
2. *Camera LED
*When the camera is in use, the LED will be illuminated.
3. Built-In Array Microphone
4. Display
5. Power Button
6. Keyboard
7. Touchpad & Buttons
The LED indicators on the computer display helpful information about the current status
of the computer.
1
2
3
3
7
6
5
