Figure 5 - Bottom & Rear Views
System Map: Bottom & Rear Views
1. Battery
2. Vent
3. Speakers
4. Mini DisplayPort 1.4
5. HDMI-Out Port
6. RJ-45 LAN Jack
7. DC-In Jack
Overheating
To prevent your computer from overheating make sure nothing blocks any
vent while the computer is in use.
Bottom Cover Removal Warning
Do not remove any cover(s) and/or screw(s) for the purposes of device
upgrade as this may violate the terms of your warranty.
If you need to replace/remove the hard disk/RAM etc., for any reason, please
contact your distributor/supplier for further information.
