Abriblue NEXTPOOL OPEN SURF SYSTEM - Preparing the Pool 4; Table of Contents; Slatted Cover Presentation

3/22 - Installaon instrucons for the OPEN SURF System and OPEN SURF System 2 above-water automac slaed safety cover
4
7
6
14
17
17
17
19
19
20
21
CONTENTS
1. Preparing the pool
1.1 Electric connecons and cable passages 4
1.2 Building work 4
1.3 Squaring checks 5
2. Delivery and Recepon
2.1 Delivery 6
2.2 Recepon 6
2.3 Necessary tools 6
2.4 Items in the container 6
3. Assembling the OPEN SURF
3.1 Composion of the rails (SURF 1 and 2) 7
3.2 Dimensions to embed the rails 7
3.3 Assembling the rails (SURF 1 and 2) 7
3.4 Fixing the stand (SURF 1 and 2) 9
3.5 Fixing the moving rail and retaining stop
(SURF 1 and 2) 10
3.6 Fix the stop. 10
3.7 Removing the covers: (Surf 1 and 2) 11
3.8 Cung the pool sides 12
3.9 Removing the solar panel
(OPEN SURF 2 solar) 12
3.10 Final overall dimensions of the OPEN SURF2
slaed cover 13
3.11 Final overall dimensions of the RAISED OPEN SURF 13
4. Electric connecons
4.1 Cabled model 14
4.2 Stand-alone and stand-alone solar models 15
4.3 Solar cabled model 16
5. Assembling the slats
6. Limit switch adjustments
6.1 End of unrolling 17
6.2 Fixing the slat cover to the roller sha 17
6.3 Adjustment of the end of rolling stop 17
7. Test instrucons in the event
of a malfuncon
7.1 For the models with a box 17
7.2 For the solar models 18
7.3 For all models 19
8. Checks
9. Recepon of the cover by the end user
10. Appendix: Solar regulator
10.1 Regulaon operaon 20
10.2 Troubleshoong 20
11. Appendix: reminder of installaon rules
11.1 Solar panel operang principle 21
11.2 Panel orientaon 21
11.3 Projected shade and surrounding vegetaon 21
11.4 Solar kit element winterisaon 22
11.5 Example of produced, stored and used energy
calculaon 22
