Absen AX Series User Manual

Leasing
Product
Installation
Cabinet Installation Method
hanging, stacking
Maximum number of hoisted cabinets
25
AX1.2 Product Specifications
Parameters
Specifications
Physical
Parameters
Pixels
IMD 4 in 1 1.27
Pixel Pitch (mm)
1.27
Cabinet Pixels
480×270
Pixel Density (Pixels / m
2
)
619414
Module size (L × W × H)/(mm)
152.5×343
Module size (L × W × H)/(mm)
610×343×80
Cabinet Material
Die-cast Aluminum
Cabinet Weight (㎏/Cabinet)
7.8
Electronic
Parameters
Color Processing Depth (Bit)
14
Grayscale
16384
Refresh Rate (Hz)
3840
Drive Mode
1/46
Picture Frame Frequency (Hz)
50/60
Signal Transmission Distance (m)
UTP cable:＜100 m; Single-mode fiber:＜10 km
Optical
Parameters
Brightness (nit)
600
Horizontal Viewing Angle (°)
160
Vertical Viewing Angle (°)
140
Electrical
Parameters
AC Input Voltage (V)
100~240
AC Input Frequency (Hz)
50/60
Maximum AC Input Power (W/m
2
)
650
Average AC Input Power (W/m
2
)
215
Environmental
Parameters
Storage Temperature (˚C)
-40~+60
Working Temperature (˚C)
-10~+40
Storage Temperature (RH)
10%~90% Non-condensing
Working Humidity (RH)
10%~90% Non-condensing
Ingress Protection
IP40/IP21
