Page #6 background imageLoading...
Page #6 background image
- 6 -
LR3.9-7.8 User Manual
1.2 Product Specifications
Remark: Power consumption tolerance: ±15%, according to the actual situation.
Parameters
LR3.9-7.8
LED Type
SMD1921
Pixel Pitch (mm)
Horizontal 3.9 - Vertical 7.8
Cabinet Pixels
256*64
Pixel Density (Pixels / m
2
)
34544
Module size (L × W)/(mm)
500*250
Panel size (L × W × H)/(mm)
1000*500*77.2
Cabinet Material
Die-cast Aluminum
Cabinet Weight (
/Cabinet)
6
Grayscale
14
Refresh Rate (Hz)
3840
Drive Mode
1/16
Signal Transmission Distance (m)
UTP cable:
100 m; Single-mode fiber:
10 km
Brightness (nit)
2500
Viewing Angle (H/V)(°)
160/150
AC Input Voltage (V)
100~240
Power Consumption
(Max/Avg.)(W/m
2
)
335/112
Storage Temperature (˚C)
-40~+60
Working Temperature (˚C)
-20~+50
Storage Temperature (RH)
10%~90%
Working Humidity (RH)
10%~90%
Ingress Protection
IP65/IP54
Product Life (hrs)
100000
Panel Installation Method
Hanging/Fixed
Maximum number of hoisted
cabinets
20
