Page #9 background imageLoading...
Page #9 background image
- 9 -
LR3.9-7.8 User Manual
1.5.2 Power Input characteristics
Input Voltage Range
90Vac to 264Vac
Normal Voltage Range
100Vac to 240Vac
Frequency Range
47Hz-63Hz
Max Input AC Current
3.5Amax. at full load condition
Inrush Current ( cold state )
60A typ. Peak@230Vac
Efficiency (full load )
89%@220VAac
Leakage Current
Less than 3.5 mA,
@ 240Vac input
Normal Output Power
250W
Input Fuse
T5AH/250Vac
Power Factor
>0.95@ full Load 220Vac input
( Universal AC Input With Active
PFC )
1.6 Receive Card
The A5S receiving card is connected to the Hub board through the card slot. Meanwhile,
the Hub board which plays the role of transit is also connected to the module, power supply
and data cable.
