2.2 Receiver overview
2.3 Accessories sold separately
Note
· To ensure the best signal quality make sure that the antenna is mounted perpendicular
to the model body in an upright position.
CH4
CH3
CH2
CH1
CH4
CH3
CH2
CH1
LED
LED
Antenna
Antenna
+ - VCC
GND
+ S
-
Item no. 2020016
4-Channel Receiver "R4WP-Micro" 2.4 GHz
Item no. 2020015
4-Channel Receiver "R4WP Int. Antenna" 2.4 GHz
Item no. 4140016
TX LiPo 2S 7.4V 1200mAh SC with LiPo Protect (JR/FUT)
