Absolute Acoustics NDS-UM Series User Manual

NDS-UM
Preset #
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
Descrip t ion
10 80 p Video | St ereo A udio
10 80 p Video | Mult ichannel Audio
10 80 p Video | High Defi nition A udio
10 80 p 3D Vid eo | Stereo Audio
10 80 p 3D Vid eo | Mult ichannel A ud io
10 80 p 3D Vid eo | High Defi nit ion A ud io
4K/ UHD 30 Hz Video | St ereo Aud io
4K/ UHD 30 Hz Video | Mult ichannel Aud io
4K/ UHD 30 Hz Video | High Defi nit ion Audio
4K/ UHD 60 Hz Video | Stereo A udio
4K/ UHD 60 Hz Video | Mult ichannel A udio
4K/ UHD 60 Hz Video | High Defi nit ion Audio
10 80 i Vid eo | Stereo Audio
10 80 i Vid eo | Multichannel Audio
10 80 i Vid eo | Hig h Defi nition A udio
1920 x10 80 DVI Vid eo | (No Audio)
At times, HDMI sources and display may not synchronize properly. UM matriz switchers feature an internal library of EDID settings to
ensure HDMI source’s output compatibility with the display devices. The con guration can be performed by device’s Web Interface, or
by sending RS232 commands. Please reset the unit by either unplugging and plugging the HDMI connections, or power cycle so that
the new settings take e ect.
EDID DATA TA BLE
