Page 18 Data : 01.03.2016
Output relay test
Switch contact status Display Note
Error dis-
play
Test
point
Lift Lower Fast
Monito-
ring
--0- 0 0 0 0 0001 all relays at rest 0000
--1- 1 0 0 0 1000 relays set to ”lift” 1001
--2- 0 1 0 0 0100 relays set to ”lower” 0101
--3- 0 0 1 1 0011 relays set to ”fast”
Part- load switch test
--4-
External part load switch test currently not active
--5-
Inputtest“E6”/“E2”/“E7”/“EA”
Input status Display Note
Error dis-
play
E6 E2 E7 EA
--6- 0 0 0 0 4000 no signal at inputs monitoring ok 0000
1 0 0 0 0001 ”lift” signal at input 4000
0 1 0 0 0020 ”lower” s ignal at input 4000
1
0
0
1
1 1
0301
0320
”fast” and “lift” signal at input
”fast” and “lower” signal at input
4000
Inputtest“E1”/“E3”/“E4”/“E5”
Input status Display Note
Error dis-
play
E5 E4 E3 E1
--7- 0 0 0 1 0005 signal at input E1 evaluated 0000
0 0 1 0 0060 signal at input E3 evaluated 0000
0 1 0 0 0700 signal at input E4 evaluated 0000
1 0 0 0 8000 signal at input E5 evaluated 0000
(0 = contact open, 1 = contact closed)
You must leave this parameter following each test.
For safety reasons, a time limit has been incorporated
for this parameter. When this parameter has been se -
lected for 45 minutes, the unit is switched automatically
back to normal operation.
To leave the diagnosis parameter, press the Enter key
for some time.
Parameter: P3.0
Display mode – load indication
(in
t)
When this parameter is selected, the last load measu-
red is indicated.
Measurement and display are only possible w ith the
motor running. When t he motor is shut down, the dis-
play is frozen.If the motor is started up again, the dis-
play is updated.
When this parameter is selected, the unit switches to a
special mode of operation
. The overload protection
function of the unit is active but the load is displayed
and not the operating hours.
Parameter: P3.1
Display mode – rotating field
power (in
kW)
When this parameter is selected, the power measured
is indicated.
Measurement and display are only possible w ith the
motor running. When t he motor is shut down, the dis-
play is frozen.
Parameter: P3.2
Display mode – load indication
(in
t)
This has the same function as parameter P3.0 except
that the overload protection function is disabled.
Parameter: P3.3
Display mode – conductor cur-
rent (in
A)
When this parameter is selected, the conductor current
measured is indicated.
Measurement and display are only possible w ith the
motor running. When t he motor is shut down, the dis-
play is frozen. If the motor is started up again, the dis-
play is updated following the measurement time.
