2. Description of hardware
2.1. HDCC32561 / HDCC35560
1
Camera base plate
2
Locking plate
3
Camera cap
4
Camera
5
Toggle switch
For switching between analogue formats
(TVI / CVI / AHD / CVBS)
6
Power supply connection
(5.5 x 2.1 mm, barrel connector)
7
BNC video output (TVI / CVI / AHD /
CVBS)
2.2. HDCC42561 / HDCC45560
1
Camera wall bracket
2
Camera
3
Lens
4
Toggle switch
For switching between analogue formats
(TVI / CVI / AHD / CVBS)
5
Power supply connection
(5.5 x 2.1 mm, barrel connector)
6
BNC video output (TVI / CVI / AHD /
CVBS)
