3.5. HDCC35560 / HDCC45560 5MPx resolution
The HDCC35560 and HDCC45560 5MPx cameras are delivered with a lower resolution (4MPx) preset.
This enables a higher frame rate (30 images per second rather than 20 images per second) and
maintains the conventional aspect ratio (4MPx – 16:9 aspect ratio, 5MPx – 4:3 aspect ratio), which
means no black bars appear when using conventional 4:3 aspect ratio monitors. You can set the
resolution in the camera’s OSD menu (see below).
The TVVR33600 analogue hybrid recorder supports resolutions up to 4MPx (TVI format).
Therefore, when using the HDCC35560 and HDCC45560 5MPx cameras with this
recorder, the resolution cannot be increased to 5MPx. If the resolution is already set to
5MPx, it will be automatically reduced to 4MPx.
4. OSD menu
The camera's on-screen display (OSD) can only be opened by devices with control capabilities
(recorder, control panel). To open the OSD menu, either use the “Iris+” option or call up preset 95. To
navigate, use the device's PTZ arrow keys and the “Iris+” option to open and confirm.
The OSD menu is only available in English. Please familiarise yourself with the description
of the points below.
The “Iris+” option may differ for each device.
MAIN MENU
General menu navigation
BACK Go back one menu step
EXIT Leave main menu without saving changes
EXIT & SAVE Leave main menu and save all changes
VIDEO FORMAT Select video format
HDCC32561 / HDCC42561:
o 2MPx with 25 or 30 images per second
HDCC35560 / HDCC45560:
o 2MPx with 25 or 30 images per second
o 4MPx with 25 or 30 images per second
o 5MPx with 20 images per second
