35
English
9. Technical data
Model number HDCC61510
Image sensor 1/3 inch progressive scan CMOS
Camera type Vario tube
Resolution 720p25, 720p30
Pixels (effective) 1920 (H) x 1080 (V)
Lens 2.8–12 mm, varifocal lens
Horizontal angle of view 32°–78°
Day/night switching Electromechanical IR cut filter
Minimum illumination (colour) 0.1 Lux
Minimum illumination (B/W) 0.001 Lux (image integration on)
Minimum illumination (IR) 0 Lux
Image integration 2x–16x
Noise reduction 3D DNR
Electronic shutter control 1/50 s to 1/50,000 s
Camera control On-screen display (OSD)
Backlight compensation DWDR
Privacy masking Eight freely configurable areas
Digital zoom Yes
Video system HD-TVI
IR LEDs 42
IR range 40 m
Smart IR Yes
Connections
Video signal (HD-TVI, BNC), video signal (FBAS, BNC), power
supply
Power supply 12 V DC ± 10%, 24 V AC ± 10%
Power consumption Max. 500 mA (max. 6 W)
Operating temperature -20°C–+60°C
Humidity Max. 90%
Dimensions (L x W x H) 267 x 92 x 115 mm
Weight 900 g
The IR range is strongly dependent on the environmental conditions. If the area in the
camera's field of view reflects poorly or if there are no objects within the max. illumination
range, the brightness of the video image at night may be too low. This will result in poor
usability of the video image.
In addition, when installing the camera it must be ensured that no objects are located in
close proximity to the camera's field of view (e.g. roof gutter or wall). These objects can
reflect back the IR light, resulting in circular fading on the video image in the opposite
direction to the object.
