8.6.4 Alarm output
You can configure the two alarm outputs here.
Alarm Output No.
Here, select the alarm output that you wish to configure.
Delay
With the "Manual" setting, the alarm output is not reset after an event. This must then be confirmed and reset
manually via the "Manual alarm" button by clicking it twice.
The regular active time of the output after the event is 5 seconds. A further active time of up to 10 minutes can
be programmed.
Alarm name
You can specify a name for the relevant alarm output here. Please do not use the alarm output no. or any
special characters.
Schedule
To save a schedule, click on "Activate schedule". Specify here on which days of the week and at which times
the alarm output should be active.
The period selection is made by holding down the left mouse button. By clicking on an already marked period,
the details can also be set via keypad or deleted again.
To copy the time selection to other weekdays, move the mouse pointer behind the bar of the weekday already
set and use the "Copy to ..." function.
Apply the settings made by clicking "Save".
