32
PTZ Dome wall installation
1. Drill four holes in the wall to match the mount and push the straddling dowels into the wall.
2. Fasten the seal between the wall and mount.
3. Use the washers and nuts when installing the mount.
4. Now place the PTZ Dome on the installation head and fix in place using the fixing screws.
The straddling dowels must be used for stone walls. Wood screws (self-tapping) can be used for
wooden walls.
Make sure that the wall is strong enough to bear more than 8 times the weight of the PTZ Dome
and its mount.
To complete installation, remove the protective film from the dome.
Straddling dowel
Washer and nut
Safet
cable
