14
LED indications
LED COLOR MODE Description
Green
On
The current connection (line rate) is more than 40
Mbps
Blink Powerline connection pairing
Orange On
The current connection (line rate) is more than 20
Mbps and less than 40 Mbps
Red
On
The current connection (line rate) is between 1 and
20 Mbps
Off No Powerline connection
Green
Off Ethernet Interface down
On/Blink Ethernet Interface up
Green On System is powered up
Indicators
