– 24 –
Item Name Comment
1 Sound outlet opening
2 Control light (LED)
The control light is located under the lid and
shines through it.
3 Test / stop button The test / stop button is activated by pressing the
lower segment of the cover.
4 Detector base with mounting holes
5 Smoke inlet opening
1
2
4
3
Packaging
• Keep packaging materials and components away from children –
risk of suffocation!
• Remove all packaging before using device.
Scope of delivery
• ABUS smoke alarm including built-in battery
• Operating instructions
• Installation equipment
Introduction | Safety information | Scope of delivery
5
